SHD - Super Heavy Duty

CODICE AH (20/H) EN(A) BASE POLARITÀ COPERCHIO DIMENSIONI SCHEDA
TECNICA
L (mm) P (mm) H (mm)
V_GR31 112 975 B01 SX MF 330 172 238 Dowload Scheda
V_CPT 112 850 B01 DX MF 345 172 234 Dowload Scheda
V_CP 112 850 B00 DX MF 345 172 234 Dowload Scheda
V_140MT 140 1100 B01 DX ML 508 175 205 Dowload Scheda
V_140DX_T 140 950 B03 DX ML 510 175 225 Dowload Scheda
V_140SX_A 140 950 B00 SX ML 513 189 223 Dowload Scheda
V_140SX 140 850 B00 SX MF 513 189 223 Dowload Scheda
V_180DX_T 180 1100 B03 DX ML 510 218 223 Dowload Scheda
V_180SX_A 180 1100 B00 SX ML 512 223 223 Dowload Scheda
V_180SX 180 1100 B00 SX MF 512 223 223 Dowload Scheda
V_200DX_T 200 1100 B03 DX ML 510 218 223 Dowload Scheda
V_200SX_A 200 1100 B00 SX ML 512 223 223 Dowload Scheda
V_200SX 200 1100 B00 SX MF 512 223 223 Dowload Scheda
V_200SX+ 200 1400 B00 SX MF 512 223 223 Dowload Scheda
V_230SX_A 230 1250 B00 SX ML 518 275 242 Dowload Scheda
V_230SX 230 1250 B00 SX MF 518 275 242 Dowload Scheda
